PD9-M-1C-SDB-IP65 - Master / 1 channel for damp areas
Hover over image to zoom
B.E.G.
Product Description
- Mini-occupancy detector designed for high-humidity locations
- One potential-free (dry) switching contact
- Version as master device
- One additional Slave device sensor can be directly connected
- Additional functions can be set up using the optional remote control.
- Spring clips for quick and easy installation in suspended ceilings and light fittings
- Includes 45mm cover ring and blinds
Typical applications: bathrooms, shower cubicles, hospitals
Technical Details
| Voltage: | 230 V AC ±10% 50 Hz |
| Dimensions: | Sensor head: Ø 36 x 28 mm, Power supply: 154 x 38 x 25 mm |
| Power consumption: | 2.2 W |
| Detection area: | vertical 360° |
| Range: | max. Ø 10 m across max. Ø 6 m towards max. Ø 4 m seated |
| Monitored area (tangential movement): | 79 m² / 2.5 m mounting height |
| Mounting height min./max./recommended: | 2 m / 5 m / 2.5 m |
| Degree / class of protection: | IP65 / Class III |
| Ambient temperature: | -25 °C to +50 °C |
| Housing: | Polycarbonate, UV-resistant |
| Cable length: | 350 cm |
| Switching power: | |
| 2300 W, cos φ = 1 | |
| 1150 VA, cos φ = 0.5 | |
| 300 W LED | |
| max. inrush current Ip (20 ms) = 80 A | |
| Type of contact: | 1x µ-contact, dry NO contact |
| Follow-up time: | 15 sec - 30 min, Pulse |
| Switch-on threshold: | 10 - 2000 Lux Mixed light measuring |
Downloads
Accessories
- IR-Adapter for Smartphones - 92726
- IR-PD9 - 92201
- IR-PD-Mini - 92159
- RC-Arc extinction kit - 10880
- Mini-RC-Arc extinction kit - 10882
- PD9-S-SDB - 92915
