PD9-M-1C-IP65-GH - for large heights & damp areas

Hover over image to zoom

  • Image 1
  • Image 2
  • Image 3
  • Image 4
  • Image 5
  • Image 6
B.E.G.
RRP: £181.20
£171.24 (inc VAT) £151.00 £142.70 (exc VAT) (You save £9.96)
SKU:
92931
Weight:
0.20 KGS
Availability:
5 - 10 Days Lead Time

 Product Description

- Mini-occupancy detector designed for high-humidity locations especially for large mounting heights
- One potential-free (dry) switching contact
- Version as master device
- One additional Slave device sensor can be directly connected
- Additional functions can be set up using the optional remote control.
- Spring clips for quick and easy installation in suspended ceilings and light fittings
- Includes 45mm cover ring and blind

Application examples: monitoring of staircases, industrial halls.

Technical Details

Voltage: 230 V AC ±10% 50 Hz
Dimensions: Sensor head: Ø 36 x 40 mm, Power supply: 154 x 38 x 25 mm
Power consumption: 2.2 W
Detection area: vertical 360°
Range: max. Ø 3.5 m across
Monitored area (tangential movement): 10 m² / 6 m mounting height
Mounting height min./max./recommended: 5 m / 10 m / 6 m
Degree / class of protection: IP65 / Class III
Ambient temperature: -25 °C to +50 °C
Housing: Polycarbonate, UV-resistant
Cable length: 350 cm
Channel 1 (lighting control, potential-free (dry))
Switching power:
2300 W, cos φ = 1
1150 VA, cos φ = 0.5
300 W LED
max. inrush current Ip (20 ms) = 80 A
Type of contact: 1x µ-contact, dry NO contact
Follow-up time: 15 sec - 30 min, Pulse
Switch-on threshold:

10 - 2000 Lux

Mixed light measuring



Downloads

Datasheet
Manual

Accessories

- IR-Adapter for Smartphones - 92726
- IR-PD9 - 92201
- IR-PD-Mini - 92159
- RC-Arc extinction kit - 10880
- Mini-RC-Arc extinction kit - 10882
- PD9-S-SDB-GH - 92933
