for cover kit 3-gang, ref.-no.: .. 403 TSA ..
for cover 2-gang with symbols, ref.-no.: .. 402 TSAP ..
for cover 4-gang with symbols, ref.-no.: .. 404 TSAP ..
Adapter frames are included in delivery: ref.-no. LS 4 AR for LS range (pre-mounted) and ref.-no. CD 4 AR for CD range. AS / A ranges without adapter frame.
Only with the ETS 3.0d version or later versions the full functionality will be available.
ETS product family: Push-button
Product type: 3-gang push-button
1 blue LED: operation indication
3 red LED: status indication

Intended use

- Operation of loads, e.g. light on/off, dimming, blinds up/down, calling up and saving light scenes, etc.
- Installation in flush box according to DIN 49073

Characteristics

- Push-button functions for switching, dimming, blinds control, valuators, light scenes, etc.
- To be completed with cover kit
- One red status LED per button
- One blue operation LED as an orientation light and to indicate the programming status
- Integrated bus coupling unit
- Transparent cover kit (included) for temporary site use without design covers
